NV4000

$53.20

404 in stock

PPV Vent, DOT 406 manway

Civacon’s NV4000 Series Pressure Vacuum Vent has a design that reduces part count by 45% for easier and quicker maintenance. The NV4000 is installed on the bottom of the manlid poppet via a 15/16″ hex nut and has been built to withstand the extreme shocks, high G-forces, excessive surge forces and vibrations that can occur when petroleum products are being transported.

Features & Benefits

  • Flow capacity of 1,600 scfh at 3-psig venting
  • Flow capacity of 3,900 scfh at 1-psig vacuum
  • Can be installed in existing 10″ manlids
  • J-slot design with external snap ring for easy removal and cleaning
  • Lightweight, durable design (14.4 oz.)
  • Temperature range from -40ºF to 158ºF (-40ºC to 70ºC)
  • No tools required for maintenance or cleaning
  • Dust screen keeps foreign material out of poppets

nv4000-data-sheet
